Dual Sensor Infrared Thermal Imaging Camera AI Facial Recognition J380 HS

Dual Sensor Infrared Thermal Imaging Camera AI Facial Recognition J380 HS

Dual Sensor Infrared Thermal Imaging Camera AI Facial Recognition J380  HS
Dual Sensor Infrared Thermal Imaging Camera AI Facial Recognition J380  HSDual Sensor Infrared Thermal Imaging Camera AI Facial Recognition J380  HSDual Sensor Infrared Thermal Imaging Camera AI Facial Recognition J380  HS
CategoriesThermal Systems & Cameras
BrandJAVOLVISION Infrared Camera Cores and Components
ModelJ380-HS
TargetMultiple targets
BrandJavol Vision
Face RecognitionAI Face Recognition
Accuracy±0.2℃
Temperature Range+30℃~+45℃
Infrared Channel Pixel384×288
Measure Distance2~7 meters
Measurement(MM)236*130*80MM*5.5PKG
Channels8
NetworkIp
DisplayFever Screening Video
Feature>361 people in one minute
Type1/2.7 inch CMOS
Resolution1920×1080
FOB portShanghai Port
Terms of PaymentT/T
Update TimeJun 26,2024
Detail Information
Product Introduction

J380 Dual Sensor Infrared Thermal Imaging Camera AI Facial Recognition is an online infrared body temperature measuring and screening equipment, which focuses on the body temperature measuring development. Our equipment has a high accuracy of ±0.2°C, multiple targets simultaneous detection, rapid measurement, acoustic alarm, intelligent video analysis and non-contact body temperature measurement technology. Furthermore, our equipment has advantages on large flow fast screening blackbody real-time calibration, AI artificial intelligence, 24 hours non-stop testing, quick installation and is suitable for the scenarios with large flow such as hospital, school, airport, railway station, subway station, expressway service, enterprise, office building and community. To prevent the propagation of coronavirus, people need to wear the mask and their body temperature should be measured. The traditional way of measuring the temperature such as using ear thermometer and mercury thermometer has some drawbacks. For example, contact cannot be avoided during temperature measurement which increases the risk of infecting coronavirus. Moreover, rich human and material resources need to be invested. Our body temperature screening equipment can solve these problems caused by traditional way and realize high sensitivity, high- quality image, compact structure, light weight, long-term testing, software control.

Features
1. Accuracy: ±0.2℃
2. Automatic temperature detection
3. Dual-sensor
4. Acoustic alert function
5. Record and capture functions
6. Multiple points simultaneous detection
7. Multiple IR video mode
8. Accurate radical positioning
9. Blackbody real-time calibration (J380-HS)
Application
Medical thermal imaging, scenarios with large flow, public area, traffic security, disease field.
Product Specification
Model
J380-HS

                                                                                                                                                                                                        Infrared Channel

Type
Uncooleed FPA
Pixel
384×288
Wavelength Range
<7.5~14μm
Field Range
25°×16°
Sensitivity
<50mk


Visible Light Channel
Type
1/2.8" CMOS
Pixel
1920×1080
Field Range
25°×16°
Field Range Audible and Visual Alarm
Build-in warning lights and speakers




 Detection Performance
Field Range High temperature
<99%
False Accept Rate
<5%
Multi-target
Support
Automatic Alarm
Support
Face recongnition
Support
Measure Distance
2~7 meters

















































                                                                                                                                                                                                                                                                                                                                                                                                                                                                                                                                                                                                                                           Measurement
Temperature Range
+30℃~+45℃,Temperature measuring range can be extended according to user requirements
Accuracy
±0.2℃
Temperature
Automatic
Maximum
Real-time display of high temperature point location and temperature value
Emissivity Correction
The emissivity is adjustable from 0.01 to 1.0, or corrected by a predefined
Background
Automatic (based on input background temperature)
Atmosphetic
Automatic (based on input reflecting ambient temperature, distance, relative)
Function Setting
Date/time, temperature unit ℃/℉/K, and language




Data Storage
Temperature Data
Custom MGT format. Analysis with IRX software
Image format
Adopted JPG for memory storage.BMP for PC. JPG
Video Format
AVI format , H.264 compression
SD Card
Build-in 32G high speed TF card
Storage Control
Serial command with level trigger
Report Generation
Wordformat with content selection orientation



Interface
Internet Interface
100M/1000M LAN, RJ45 interface. Temperature data transmission
Video Output
SMA RFI
Control
RS232、RS485
Alarm Input
Always closed. Always opened
API
Support SDK(Win&Linux),and ONVIF agreement
Power System
Operating Voltage
DC: 12V
Power Consumption
<30W


Environmental Parameters
Operating Temperature
30℃~+60℃
Storage Temperature
-40℃~+70℃
Humidity
≤95%(RH)
EMC
Match with CE/FCC
